Tungsten Carbide Drill Bits T38 127mm Rock Drill Bits With CNC Milling Heat Treatment Process
Description:
The thread button drill bits are made by high quality alloy steel bar and tungsten carbides. Through heat treatment, our drilling tools are tough enough to meet rock drilling demands and have the least loss of energy while drilling the rocks. Besides, we can design customized thread button drill bits according to different drilling application, and custom drill bits are applicable to drill soft rock, loose-medium rock and hard rock.
Rock Drill Thread Button Bits is suitable for R22, R25, R28, R32, R35, R38, T38, T45, T51, ST58, T60 rock drill rods use. It have many thread. It's widely used for hard rock(f=8~18) drilling use.
Specification
| Name of Product | Diameter | Tip size(mm) | No. of Flushing Holes | Weight (kg) |
| mm | Gauge | Front | Side | Side |
| T38 Thread | 57 | 5*11 | 3*10 | 1 | 1 | 1.6 |
| 64 | 5*12 | 3*11 | 1 | 1 | 1.6 |
| 76 | 5*14 | 3*12 | 1 | 2 | 2.4 |
| T38 Thread | 64 | 8*9 | 4*9 | 2 | 2 | 1.8 |
| 76 | 8*11 | 4*10 | 2 | 2 | 2.6 |
| 89 | 8*12 | 6*11 | 2 | 2 | 3.3 |
| 102 | 8*13 | 6*12 | 2 | 2 | 4.7 |
| T38 Thread | 64 | 6*10 | 4*9 | 0 | 3 | 1.7 |
| 70 | 6*11 | 4*10 | 0 | 3 | 2.2 |
| 89 | 6*14 | 4*12 | 0 | 3 | 4.3 |
| T38 Thread | 64 | 8*9 | 5*8 | 0 | 4 | 1.7 |
| 70 | 8*10 | 5*9 | 0 | 4 | 2.2 |
| 76 | 8*11 | 5*10 | 0 | 4 | 2.7 |
| 89 | 8*12 | 6*11 | 0 | 4 | 3.3 |
| 102 | 8*13 | 6*12 | 0 | 4 | 4.7 |
| T38 Retract Thread | 60 | 8*9 | 3*9 | 2 | 2 | 1.7 |
| 64 | 8*9 | 4*9 | 2 | 2 | 2.0 |
| 70 | 8*10 | 4*10 | 2 | 2 | 2.4 |
| 76 | 8*11 | 4*10 | 2 | 2 | 3.2 |
| 89 | 8*12 | 5*12 | 2 | 2 | 5.8 |
| T38 Reract Thread | 64 | 8*9 | 5*9 | 0 | 4 | 1.9 |
| 70 | 8*10 | 5*10 | 0 | 4 | 2.4 |
| 76 | 8*11 | 5*10 | 0 | 4 | 3.3 |
| 89 | 8*12 | 6*11 | 0 | 4 | 5.3 |
